SIRUI G-X, C-X, K-X & L SERIES
PROFESSIONAL BALL HEADS
1. Separate adjustment     knobs for panning,     friction control and     locking for maximum     control and flexibility.

2. The G-10X/20X have     two bubble levels (one     on top and one on the     clamp locking knob) for     fast horizontal and     vertical alignment.

3. Sirui’s unique locking     mechanism provides     unequaled locking     force even with loads     up to 44lb (20kg)!

WHY SIRUI BALLHEADS?


Each assembled component of SIRUI Ball Heads is
produced by CAM (Computer Aided Manufacturing) -
the ultimate in precision manufacturing techniques.

SIRUI ball heads are made of aviation quality
aluminum alloy 7075-T6 and 6067-T6 for
long life and maximum strength.

SIRUI uses a special manufacturing technique that
produces the support ball with tolerances to within
0.01mm of a perfect sphere. This uncompromising
precision guarantees superior performance and
smooth operation for any type of 35mm DLSR or
medium format camera system.

The interior locking system in SIRUI Ball Heads uses
SIRUI designed double bevel locks for outstanding
locking performance and reliability. Most ball heads
only use a single, less efficient interior locking system.

The panning base is designed with a 360° dial.
Having a separate panning base lock knob provides
greater accuracy for panning and panoramic shooting.

The patented safety lock design, and SIRUI quick
release plates, effectively prevent the camera from
accidentally sliding off of the ball head. And most Arca-compatible quick release plates can be used on
SIRUI Ball Heads (Note: safety lock design not
available from other brands).

The custom anodized surface treatment makes all
metal surfaces highly resistant to abrasions and
produces a beautiful appearance.

All Sirui Ball Heads are Arca-Compatible

1. Separate control knobs     for panning and lock-     ing. Friction knob is     conveniently located
    on the main locking     knob.


2. Triple bubble levels     allow precise horizontal     leveling for critical     shooting situations.

3. Sirui’s unique locking     mechanism provides     unequaled locking     force even with loads        up to 77lb (35kg)!

G-X, K-X, C-X & L SERIES BALLHEADS
Item #
Sirui
Model #
Ball
Diameter
Base
Diameter
Height
in (mm)
WGT
lb (kg)
Load
lb (kg)
Comes
With
MSRP
BSRG10KX
G-10X
29
Ø 42
3.5 (90)
0.7 (0.31)
39.7 (18)
TY-50X QRP
$135.95
BSRG20KX
G-20X
36
Ø 50
3.9 (100)
0.8 (0.38)
44.1 (20)
TY-50X QRP
$145.95
BSRK10
K-10X
33
Ø49
3.8 (96)
0.9 (0.41)
44.1 (20)
TY-50X QRP
$159.95
BSRK20
K-20X
38
Ø 54
4 (101)
0.9 (0.41)
55.1 (25)
TY-50X QRP
$174.95

BSRK30

K-30X

44

Ø 61

4.3 (109)

1.2 (0.55)

66.1 (30)

TY-60X QRP

$189.95

BSRK40

K-40X

54

Ø 75

4.9 (124)

1.8 (0.8)

77.2 (35)

TY-70X QRP

$219.95

BSRC10
C-10X
29
Ø 44
3.3 (85)
0.5 (0.22)
28.7 (13)
TY-C10 QRP
$99.95
BSRL10
L-10
Ø 43
3.7 (87)
0.7 (0.33)
33.1 (15)
TY-60 QRP
$139.95
